Walking body voltage (ANSI/ESD S97.2)
Requires ESD footwear
Value-engineered
ESD epoxy material cost
Features & Benefits
Why Choose GroundWorx™ Basics?
Durable
GroundWorx Basics creates a finished ESD floor that’s stronger and more durable than ESD paint. So strong that it resists damage from forklifts and heavy machinery—making it ideal for warehouses, shipping/receiving areas, and manufacturing spaces.
Attractive
GroundWorx Basics is available in a variety of colors with a matte finish. If you prefer a high-gloss shine, simply spread StaticWorx CoatZF floor finish over the epoxy base. While CoatZF does not add any essential ESD properties to GroundWorx Basics and is not necessary for ESD performance—many of our customers prefer the high gloss shine provided by CoatZF to the GX Basics matte finish.
Easy Installation
GroundWorx Basics spreads like paint and can be applied directly over most subfloors, including wood, VCT, coatings and concrete. GX Basics is the only two-part ESD epoxy coating that’s easily applied by novices – in fact, many of our clients apply their GX Basics floor themselves.
Meets ANSI/ESD Guidelines
GroundWorx Basics offers permanent conductivity and is fully compliant with all recommended guidelines for static-control flooring in an ESD-Protected Area per ANSI/ESD S20.20.
Low Cost. High Value
With a material cost of < $1.00 per square foot, GroundWorx Basics is an ideal ESD flooring option for low-cost projects and budget-minded clients. It’s also perfect for temporary and leased spaces – or any space in need of an ESD floor where a capital investment doesn’t make sense.
Low VOC / Water-Based
GroundWorx™ Basics is a water-glycol, low-VOC epoxy coating designed for use in occupied facilities. Reduced odor and lower emissions make installation safer and more comfortable for installers and on-site staff, while still delivering permanent ESD performance.
Application and Maintenance
Proper preparation, application, and maintenance are key to getting the most out of your GroundWorx Basics ESD epoxy floor. By following a few straightforward steps—cleaning and prepping the subfloor, correctly applying the catalyzed epoxy, and maintaining the surface with recommended products—you’ll ensure a durable, attractive, and fully compliant ESD floor that performs reliably for years.
Prior to coating, floor surfaces must be free of any release agents, curing compounds, salts or efflorescence. Before applying GroundWorx Basics, sweep and then wash the floor with an appropriate cleaning product to remove oil, grease, and soil. Follow by etching the surface with an etching solution. Then rinse thoroughly with clean water.
If the floor has been previously coated, clean a small area, rough up with a screen disk using an 80-grit screen, and then apply sealer to test for adhesion, lifting, etc. Any areas of the existing coating that display poor adhesion should be stripped. Wash the stripped areas, acid etch, and rinse thoroughly. Allow the floor to dry.
Catalyzed GroundWorx Basics should be used within six hours of mixing. Therefore, prepare only the quantity necessary for immediate use. Add pre-measured catalyst to epoxy base. Stir gently until the catalyst has been thoroughly mixed in. Allow catalyzed GroundWorx Basics to stand for 5 minutes. Apply catalyzed GX Basics with a short-nap roller in thin, uniform coats. The initial coat will cover approximately 400-500 ft2 per gallon. Allow the initial coat to dry for 5-7 hours then apply a second coat. Second coat coverage is approximately 500-600 ft2 per gallon.
Under normal curing conditions, the finished floor may be opened to light traffic after 12 hours. Complete curing with maximum durability and chemical resistance will take 5-7 days.
Using StaticWorx maintenance products, GroundWorx Basics epoxy is easy to clean and maintain. Simply apply StaticWorx Eco Scrub degreaser, followed by ScrubWorx cleaner, and CoatZF Sealer.
NOTES
Product not recommended for applications that experience reoccurring standing water.
New concrete floors should be allowed to cure a minimum of thirty days before applying any epoxy coating or finish, including StaticWorx GroundWorx Basics.
Application to floors colder than 60°F is not recommended.
Available Colors
Platinum
Pewter
Beige
Teal
Emerald
Black
What Clients are Saying
We are 10 months in our new facility. We had damaged several floor tiles during the move but I will say replacing them was painless. Our facility guy wasn’t overly excited with the decision of going with the tile over the epoxy floor but now that he has had a chance to work with it he is glad we went with the tile. We worked with our cleaning crew and have worked out a cleaning/polishing process that really shows off the floor. It was a pleasure working with both of you on the project.
…the floor is awesome! It’s very durable and it’s very convenient that we can lift tiles up to remove debris from underneath, and even replace tiles if they are damaged. So from a functional perspective, this is the best floor for our manufacturing operation.
You would never know it was ESD, WHICH IS AMAZING! Your product rocks and I’m so glad we were able to find an attractive solution that didn’t leave us with some run-of-the-mill ugly disaster in the middle of our workspaces!
Your product is impervious to most/all conditions. It’s impressive. Happy to be working with StaticWorx.
StaticWorx GroundWorx™ Basics
Technical Information & Support
Specifications
(ANSI/ESD STM 7.1)
(ANSI/ESD STM 97.1)
(ANSI/ESD S97.2)
(ASTM F-101C)
(Sward)
(Gardner)
(SCOF)
(DIN EN 433)
(ASTM D1044)
Chemical Resistance (30-minute Exposure Time)
Chemical Resistance (60-minute Exposure Time)
Further Reading
StaticWorx GroundWorx™ BasicsFrequently Asked Questions
What is GroundWorx Basics?
GroundWorx Basics is a value-engineered ESD epoxy coating that provides a durable, attractive, and low-cost static-control flooring solution. It’s ideal for warehouses, manufacturing areas, shipping/receiving zones, and any space where ESD protection is needed.
How is GroundWorx Basics different from ESD paint?
Unlike ESD paint, GroundWorx Basics creates a stronger, more durable surface that resists damage from heavy machinery, forklifts, and frequent traffic. It’s a permanent ESD solution that meets ANSI/ESD S20.20 standards.
What colors and finishes are available?
GroundWorx Basics is available in multiple colors, including Platinum, Pewter, Beige, Teal, Emerald, and Black. It comes in a matte finish, with the option to add a high-gloss shine using StaticWorx CoatZF floor finish.
How do I maintain a GroundWorx Basics floor?
Maintenance is simple using StaticWorx products: Eco Scrub degreaser, ScrubWorx cleaner, and CoatZF Sealer. Regular cleaning keeps the floor looking good and ensures ESD performance is maintained.
How long does it take for the floor to cure?
Under normal conditions, the floor is open to light traffic after 12 hours. Complete curing for maximum durability and chemical resistance takes 5–7 days.
Can GroundWorx Basics be repaired if damaged?
Yes. If the surface gets scratched or damaged, a new coat can be applied directly over the existing floor. Repairs are quick, easy, and cost-effective.
Is GroundWorx Basics safe and compliant?
Yes. It meets ANSI/ESD S20.20 guidelines for ESD-Protected Areas, and it provides permanent conductivity for reliable static control.
Can it be used in areas with heavy machinery or forklifts?
Absolutely. GroundWorx Basics is designed to withstand heavy loads, making it suitable for warehouses, shipping zones, and industrial spaces.
How much does GroundWorx Basics cost?
Material costs are under $1.00 per square foot, making it an excellent option for budget-conscious projects, temporary spaces, or leased areas.
Upgrade to GroundWorx Ultra – Maximum Performance
Experience the ultimate in ESD protection with GroundWorx Ultra. This premium Generation 3 epoxy coating delivers a high-performing, static-free surface that stands up to heavy loads like forklifts and manufacturing equipment. Quick to install, easy to maintain, and available in multiple colors, GroundWorx Ultra offers superior durability and reliable static control for electronics manufacturing, medical facilities, and any space where performance matters.
