Precision-milled tolerance delivers perfectly square, gap-free tile installations
Load rating supports forklifts, pallet jacks, and heavy industrial equipment
Guaranteed ESD and material performance for the life of the floor
Engineered for Demanding ESD Environments
AmeriWorx® ESD Solid Vinyl Tile is purpose-built for facilities where static control, durability, and operational continuity are non-negotiable. Precision-milled for exceptional dimensional accuracy, each tile installs tightly and consistently, creating a clean, professional floor that performs reliably in high-traffic, high-load environments. Permanent static-control properties are embedded directly into the material, eliminating the need for waxes, polishes, or ongoing ESD reapplication.
From electronics manufacturing and cleanrooms to data centers and industrial production areas, AmeriWorx delivers a combination of fast installation, immediate usability, and long-term performance. With no downtime after installation, proven compliance with industry standards, and a design focused on lowering total cost of ownership, AmeriWorx provides a solid foundation before diving into the specific benefits that set it apart.
Why Choose AmeriWorx® ESD Solid Vinyl Tile?
Precision-Milled for Gap-Free Installations
AmeriWorx® ESD Solid Vinyl Tile is precision-milled after acclimatization to achieve exceptionally tight tolerances, producing perfectly square, dimensionally stable tiles. This results in clean, gap-free installations that look better, install faster, and stay that way over time. Unlike die-cut vinyl tiles that shrink or creep with temperature and humidity changes, AmeriWorx installs tightly without the need for costly seam welding.
Permanent Static Control — No Wax, Ever
AmeriWorx delivers permanent static-control performance built directly into the tile during manufacturing. Conductive particles are embedded throughout the material, ensuring consistent ESD protection for the life of the floor. There is no need for topical waxes or dissipative polishes that wear off, require frequent reapplication, and add long-term maintenance costs or compliance risk.
Built for Heavy Loads and Harsh Use
With a 3 mm (1/8”) solid vinyl construction and a 2500 PSI load rating, AmeriWorx is engineered to withstand forklifts, pallet jacks, and heavy industrial equipment. The thicker tile also helps mask minor subfloor imperfections, producing a smoother finished surface that performs reliably in demanding production and manufacturing environments.
Fast Installation with Zero Downtime
When installed using pressure-sensitive adhesive, AmeriWorx tile can handle traffic immediately after installation. There is no cure time, no adhesive seepage through seams, and no disruption to operations. Faster installation and immediate usability translate into reduced labor costs and minimal impact on production schedules.
Lower Total Cost of Ownership
AmeriWorx combines long service life, reduced maintenance requirements, and efficient installation to deliver one of the lowest total costs of ownership among resilient ESD flooring options. Eliminating waxing, stripping, and re-testing cycles significantly reduces ongoing maintenance expenses while preserving consistent ESD performance year after year.
Proven Compliance and Long-Term Assurance
AmeriWorx ESD vinyl tile meets ANSI/ESD S20.20 requirements and is available in both conductive and static-dissipative ranges to match application needs. ESD and material performance are guaranteed for the life of the floor, providing long-term confidence for facility managers, specifiers, and contractors.
What Clients are Saying
AmeriWorx SVT allowed us to greatly increase our productivity. With the tiles being perfectly square and having no variation in gloss or thickness, we essentially improved our productivity by as much as 20%. Considering that labor is as much as 30% of the total cost of a new floor, that can mean the difference between a contractor making money or losing money on a tight project.
The StaticWorx products were instrumental in our success on the project. The installation process using GroundTack adhesive helped us bid and install static-dissipative tile at a production rate well above our historical levels. Our installers were genuinely impressed with how square, true, and consistent the product was. We are happy, and more importantly, our customers are happy. StaticWorx AmeriWorx is a superior product and we look forward to working with StaticWorx in the future.
Ideal Applications
Where AmeriWorx® ESD Vinyl Tile Performs Best
Explore Our AmeriWorx Collections
Product Specifications
StaticWorx ESD Carpet Tile Technical
Information & Support
Size
12” x 12”
24” x 24” and 36” x 36” available as a custom order
Grounding Material
One 2” x 24” copper strap installed every 1000 ft.
Electrical Performance
Surpasses recommended standards of ANSI/ESD S20.20.
Lifetime warranty for static control
Resistive Characteristics
- ANSI/ESD.S7.1-2013
- Conductive = < 1.0 x 10E6
- Static Dissipative = ≥ 1.0 x 10E6 and < 1.0 x 10E9
Floor & Footwear Resistance in Combination with a Person
ANSI/ESD STM97.1 < 3.5 x 10E7
Voltage
ANSI/ESD STM97.2 < 25 volts with conductive footwear
AmeriWorx® ESD Solid Vinyl TileFrequently Asked Questions
What makes AmeriWorx ESD vinyl tiles different from regular vinyl or VCT?
AmeriWorx tiles are precision-milled for perfect square dimensions, have permanent embedded ESD properties, and are thicker and more durable than typical vinyl or VCT. They install tightly with no seam gaps and do not require wax or polish to maintain static control.
Do AmeriWorx tiles require ESD wax or polish?
No. Static-control properties are built directly into the tile material, so there’s no need for topical ESD treatments. This reduces maintenance costs and ensures consistent performance over the life of the floor.
Can AmeriWorx vinyl tiles handle heavy industrial equipment?
Yes. Each tile is 3 mm thick and rated at 2500 PSI, allowing it to support forklifts, pallet jacks, and other heavy machinery without damage.
How quickly can the floor be used after installation?
When installed with StatBond pressure-sensitive adhesive, the floor can handle traffic immediately—no downtime or curing time is required.
Are AmeriWorx tiles ANSI/ESD S20.20 compliant?
Yes. All AmeriWorx tiles meet ANSI/ESD S20.20 standards, with options available in both conductive and static-dissipative ranges. Conductive tiles are <1.0 × 10⁶ ohms, and dissipative tiles range from >1.0 × 10⁶ to <1.0 × 10⁹ ohms.
Are the tiles environmentally friendly?
Yes. AmeriWorx is FloorScore® certified, contains no measurable VOCs, and meets California 1350 indoor air quality standards.
Can these tiles be heat-welded?
Yes, if desired. However, heat-welding is never required due to the precision-milled, gap-free design of the tiles.
Where can AmeriWorx ESD tiles be installed?
They can be installed over wood, concrete, and access floors and are ideal for electronics manufacturing, cleanrooms, biotech areas, data centers, hospitals, MRI suites, and other mission-critical environments.
How do AmeriWorx tiles compare to Armstrong or other vinyl flooring?
AmeriWorx is superior in terms of dimensional accuracy, durability, embedded static-control performance, and installation speed. Unlike competitors that require wax, polish, or downtime, AmeriWorx tiles provide immediate, permanent ESD protection and reduce total cost of ownership.
What is the total cost advantage of AmeriWorx tiles?
By eliminating waxing and polishing, reducing labor time, and offering direct-to-contractor pricing, AmeriWorx provides one of the lowest total costs of ownership among resilient ESD flooring options.
